4-20ma china High Temperature Melt Pressure Transmitters

FOB Reference Price:Get Latest Price
$175.00 - $298.00 / Piece | 1 Piece/Pieces (Min. Order)
Support Sea freight
Report Suspicious Activity
Quick Details
Place of Origin:
Hunan, China
Brand Name:
Model Number:
HPT124 Pressure Transmitters
≤ ±0.5%F.S; ≤ ±0.25%F.S; optional
0-10 Bar......1500 Bar / 0-150Psi......20000Psi G Optional.
Working Temp:
Output signal:
4-20 mA; 0-10V; 0-5V optional.
Electronic wire::
5Cores or 6 Cores/Pins/Wires
Medium compatible::
Various media compatible with the 316L stainless steel
Power supply:
24V DC
Process connect port::
1/2''-20UNF Male; M14*1.5; M20*1.5... (by customized)
Thermocouple type:
J,K,E, PT100 Optional
Supply Ability
Supply Ability:
5000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Holykell standard carton box for 4-20ma Pressure Transmitters, ensure goods well intact when receive.
Shenzhen/Shanghai/ Any port of China

4-20ma china High Temperature Melt Pressure Transmitters


Why Choose and trust HOLYKELL ?

You benefits from:

Factory Experience

More than 16 years of experience in Level sensor industry.
large stock :

within 24 hours delivery for standard specifications.
Supply Ability :

At least 50000 pcs per Month.
Supply Area :

All over the world, about 109 countries (Most of them are from North America, Europe, Australia,Asia and Africa


You Credit Guarantee  :

♦ Trade Assurance: 558 Transactions, total amount is above $ USD 361,000+
♦ Near 50% buyers found water level sensor and contact us, Holykell in
♦ View Holykell 6000+, Send inquiry 200+, Quote 400+ (half of 2017 years)


Why Choose Our High Temperature Melt Pressure Sensor Transmitter?

1. The product is widely used for pressure measure and control of petroleum, chemi-industry, metallurgy, power station and hydrology and so on.

2. 4-20ma;0-5V;0-10V;0.5 to 4.5V is standard output, which is amplified signal, means it has better stability and long-distance transmission ability, quick response.

3. small volume easy to fix in some cramped space. Easy operation and fitting.

4. Needs to be connected with indicators or PLC etc., to read out the pressure value., you can consider our indicator PI600 serious.

5. Regular cleaning and checking is necessary.

6. If there is high temperature environment, performance will be influenced more or less, which we called temperature shift.



Product Description

 Product Description of Holykell High Temperature Pressure Transmitter Sensor:

HPT124 Series melt pressure Transducer’s instruments for high-temperature fusion pressure Transducer is applicable for measuring and controlling pressure ofhigh-temperature articles in the fields of chemical fibers, plastics and rubber or high-temperature resistant fluid. By assimilating advanced technologies of similar international products and using imported raw materials and key elements, the instrument is characteristic of stable operation, reliable performance, high accuracy, strong output signal, excellent dynamic performance and slight high-temperature resistant zero drift. If HPT124 series Transducers are jointly used with PY series instruments manufactured by us, then all requirements of customers can be fully satisfied. It can be also be used with import instruments without any adjustment or modification.


What's the Specification of 4-20ma china High Temperature Melt Pressure Transmitters?



Holykell HPT124 series high tempertaure oil melt pressure sensor

Model No.:

HPT124-121; HPT124-230; HPT124-125; HPT124-233

Pressure Type:

Gauge Pressure

Pressure Range:

0-10 Bar……1500 Bar / 0-150Psi……20000Psi G Optional.

Power Supply:

24V DC

Electronic Wire:

5Cores or 6 Cores/Pins/Wires


4-20 mA; 0-10V; 0-5V optional.


1.2 times Full Range.

Burst Pressure:

1.5 times Full Range.


(Linearity; Hysteresis;


≤ ±0.5%F.S;

≤ ±0.25%F.S;




Working Temp:


Storage Temp:


Medium compatible:

Various media compatible with the 316L stainless steel





Permanent Stability (1 Year):

0.3% F.S.O

Bridge impedance:

350 ohms±10%

Insulation Resistance:

≥3000 MΩ

Electronic connection:

Fixed cable Explore Proof and water proof IP67;

5 Pin Plug; 6 Pin Plug IP65;

Terminal Box (Hirschman) IP65.

Process connect port:

1/2’’-20UNF Male; M14*1.5; M20*1.5… (by customized)

Thermocouple type

J,K,E, PT100 Optional

Response time:

≤10 ms

Certificate approve:

CE Certificate.

Explore Proof:

Exd II CT5

EMC Standard:

electromagnetic radiation:EN50081-1/-2

electromagnetic susceptibility:EN50082-2


Special applications request by customized
