Holykell factory Low cost engine generator oil pressure sensor HPT907

FOB Reference Price:Get Latest Price
$19.00 - $55.00 / Pieces | 10 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Hunan, China
Brand Name:
Holykell
Model Number:
HPT907
Type1::
oil pressure sensor
Application::
Refrigeration,Compress Pressure Transmitter
Typical Accuracy::
0.5%F.S
Electronic Connect::
Packard Connector 3 Pins
Pressure Range::
0-2 Bar.....600Bar Optional
Certificate approving::
CE Certificate.
Water Proof::
IP67
Type2::
Refrigeration Pressure Transmitters
Type3::
Low cost pressure transmitters
Type4::
compressor pressure sensors
Supply Ability
Supply Ability:
12000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Export Packing
Port
Shenzhen\Guangzhou

Holykell factory Low cost engine generator oil pressure sensor HPT907

       hot selling engine generator oil pressure sensor

 You will benefit from our 18  years level and pressure measurement experiences and  18 months warranty, 0 return back rate ,0.015% maintence rate.

Product Description



1.Suitable for wall hanging furnace, gas furnace, gas storage, etc all kinds of hydraulic, pneumatic pressure measurement
2.Suitable for civil use product batch
3.Static accuracy: plus or minus 1.0% FS
4.Pressure range 0-1.2 MPa (can be customized according to customer requirements)
5.Wide range of temperature compensation
6.Medium for non-corrosive gas, water, oil, etc



The HPT907 series is a new performance standard for low cost, high volume, commercial and industrial applications. the HPT907D is suitable for measurement of liquid or gas pressure. The unique design of the HPT907D pressure transducer utilizes the innovative digital compass and provides highly precise and reliability measurement. Combining the latest digital compensation and the professional sensor technology, this Pressure Sensor is suitable for measuring the pressure of non-corrosive gas and liquid. And the leak-proof devise in its construction can ensure its safety.

This pressure sensor has CE and ROSH license.





Specifications:

Model:

Parameter:

HPT907A/B/C/D

Pressure Range

0 ~2bar/5bar/8Bar/10Bar/12Bar/25Bar…

Other range 0~100bar……600Bar(price is higher)

Body materials:

Carbon steel alloy or Stainless steel

Overload

150%

Accuracy

±1.0%F.S.(Typical); ±1.5%F.S.(Typical)

Max Error:

± 1.5 %FS~±3%F.S. (including 0 ~ 90  temperature error)

Working Temp

-30~105

Storage Temp

-40~85

Supply voltage

5.0 ± 0.5VDC; 24VDC, 12~36VDC.....

Output voltage

0.5 ~ 4.5VDC;4-20mA; 0-5V.....

Pressure cycle life

500,000

Protection

IP65

Pressure port

G1/4

G1/2

By customized (price is higher)

Measures media

Air, water, oil and other non-corrosive, non-solvent medium

Vibration

10Hz,3mm/ one hour

Certificate approving:

ROSH and CE Certificate.

Remarks:

Special applications request ,can custom by order





How to place order?



In order to recommend you the most suitable sensor , please show us  following necessary info according to your practical situation.

1. what is your application ?

2. what purpose do you want to get ?

3.what is your medium ? and  working temperature ?

4.what is your requirement on specifications as follow:

   pressure range ?

   threaded screw?

   output signal?

   Electronic connection ?

   Whether need cable ?

   Accuracy ?

5.feedback us above data and your order quantity.



Or you can send inquiry to:

Mail: sales07(at)holykell.com









Order services

Fastest reply:Professional sales engineers 7/24 online services

Payment terms:T/T ,Western union, Paypal, Credit Card, L/C, Escrow others

Fast delivery: within 24 hours release the cargo (normal spec.),Customized 7-12 days after payment .





MAINTENANCE & AFTER-SALES SERVICES



Customer Feedback:  Sales engineers and technical engineers will be one-on-one service for you to exclude all obstacles when use our sensors.

Warranty period: 18 months

Product life-long maintenance: Holykell can provide you with the maintenance of the whole life of the sensors





Company Information

Holykell Technology Co. , Ltd is a high-tech company integrating R&D, production and distribution. The company has a purification plant of 5000m2, an annual output of 1 million production line of pressure sensor, transmitter and intelligent digital instrumentation.

Now the company has more than 120,000 customers worldwide, the products have been exported to Europe, America, Australia, Africa, southeast Asia, 109 countries.

Holykell can provide a cost effective solution for pressure monitoring for a variety of applications. Welcome to your inquiry.





Certifications

HPT907(pressure sensor) have obtained the European Union ATEX, TUV, Rosh certification, And Holykell has passed ISO9001:2015 international quality management system to certify that its mature and advanced technology can protect your project.
