Water, Storage containers, process vessels or strong dust and so on
Screw , Flange
4 - 20mA / HART ( Two - wire / Four - wire ) RS485 / Mod bus
Valid from 2018-05-09 until 2049-12-31
5000 Unit/Units per Month Distance Radar Level Sensor
Packaging & Delivery
Standard box for radar level sensor for Distance Radar Level Sensor
1 - 10
To be negotiated
Holykell Factory Radar Distance Measurement High Frequency Radar Level Sensor
1.Summary Radar Level Transmitter is high-frequency level measurement instruments with the maximum measuring distance up to 70 meters. The antenna is further optimized, and the new-type microprocessor can perform higher rate of signal analysis and processing, making the instrument available for complex measurement conditions, such as reactors,solid silos.
2. Priciple Radar Level Antenna emits narrow microwave pulses that transmitted down by the antenna. The microwave comes into contact with the measured medium surface then reflected back and receiving by the antenna system. The signal is transmitted to electronic circuit and partly concert to level signals ( sa the microwave featured with high propagation speed , it ' s almost instantaneous for the electromagnetic waves to reach the target and retum to the receicer).
3.Feature : >>With small antenna size,easy to install,non-contact radar,no wear,no pollution. >>Almost free from corrosion, foamimpact; hardly affected by the change of the temperature,pressure and water vapor in the atmosphere. >>Severe dust environment is not likely to affect the work of the high-frequency level transmitter. >>Shorter wavrlength can achieve better reflection for the inclined solid surface. >>The small field angle and energy concentration enhanced echo capabilities, and beneficial to avoid interference. >>Minimized measuring blind spot can gain better result in better performance. >>High SNR, even in the case of fluctuations can result of small tank measurement. >>High frequency is the best choice to measure solids and low dielectric media.
Application: HR263 4-20mA silo level measurement radar level sensor Measuring range: 70m Process connection : Screw , Flange Medium Temperature: -40~250℃ Process pressure: Atmospheric Precision : ± 15mm Frequency tange:26GHz Safety grade: IP67 Anti-explosion: Exia ⅡC T6 Ga Signal output : 4 - 20mA / HART ( Two - wire / Four - wire ) RS485 / Mod bus
