Holykell Factory HTS104 400 Centigrate Temperature Sensor Display

FOB Reference Price:Get Latest Price
$79.00 - $159.00 / Piece | 1 Piece/Pieces (Min. Order)
Lead Time:
Quantity(Pieces) 1 - 10 >10
Est. Time(days) 15 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Hunan, China
Brand Name:
Holykell
Model Number:
HTS104 Temperature Sensor Display
Type:
Insert Type
Power supply::
11~36Vdc
Output::
4-20mA/0~5V/0~10V
Linear::
±0.1%F.S.; ±0.3%F.S.; ±0.5%F.S. Optional
Materials:
304/316 stainless steel
Range::
0~200 degree
Water Proof:
IP65,IP68
Probe length::
50mm
Probe Dimension::
6mm, 8mm optional
Long time stability::
0.1%F.S.
Supply Ability
Supply Ability:
5000 Piece/Pieces per Month Temperature Sensor Display
Packaging & Delivery
Packaging Details
standard carton box
Temperature Sensor Display
Port
Any port in China
Lead Time :
Quantity(Pieces) 1 - 10 >10
Est. Time(days) 15 To be negotiated

Holykell Factory HTS104 400 Centigrate Temperature Sensor Display





Model: HTS104

Range:0-400°C

Output: 4-20mA /0~5V/0~10V

Certificate: CE , ISO9001



Characteristic:



Simple installation and multifarious-temp scope



Gas and liquid medium available



Medium compatible 316L stainless steel



Excellent long time stability and lower consumption



Smaller dimension and Compact structure



Response fast and high accuracy



Various linear analog signal output optional



Highly-efficient RFI & EMI resistance



Automotive compensation digital circuits



Applications:



pipeline and ventilation system

 Hydraulic and pneumatic system

Petrochemical industry

Hydraulic and pneumatic systems

Cooling system

Heating system

Air Conditioning System (HAVC)

Automatic system temperature measurement and control

Agricultural Greenhouses application



Specifications:



Model:

Parameter:

HTS101

HTS102

HTS103

HTS104

Measurement Range (Degree C/ °C):

-50~0; -50~50; 0~80; 0~100; 0~120;0~150

0~200 optional

0~250; 0~300;

0~400 optional

-50 to 400 optional

Installation Type:

Insert type

Insert type

Insert type

Insert type

Probe length:

50 mm or customized

50 mm or customized

50 mm or customized

50 mm or customized

Probe Dimension:

Φ6; Φ8 optional

Φ6; Φ8 optional

Φ6; Φ8 optional

Φ6; Φ8 optional

Sensor Type:

PT100; Pt1000

PT100; Pt1000

PT100; Pt1000

PT100; Pt1000

Signal Output:

resistive signal

4-20 mA                       0-5V                 0-10V

Signal wires type:

2 wires or 3 wires

2 wires

3 wires

Power supply:

NA

11~36Vdc

18~36Vdc

Linear:

±0.1%F.S.; ±0.3%F.S.; ±0.5%F.S. Optional

Working pressure:

40Bar (standard); 300 Bar (customized)

Long time stability:

0.1%F.S.

Response time:

T=50 2.3S; T=90 5.4S

Electronic proof:

NA

Reverse polarity protection; Overload voltage protection (standard);

surge protection (customized)

Environment temp:

-40~85 Degree C

Storage temp:

-40~125 Degree C

Materials of housing:

316L Stainless Steel

Materials of process:

316L Stainless Steel

Water proof:

IP65



Demension:



  temperature sensor 0-10v

PHOTOS:



temperature sensor 4-20ma



Payment and delivery:

temperature sensor pt100

temperature sensor 0-10v
